The Under Current Recirculating Deep Water Culture (RDWC) System features the patented Sub-Current Culture circulation method. This high-performance water culture system is unmatched in efficiency, layout versatility, and ease of use. The Under Current® utilizes negative water pressure to recirculate oxygenated nutrient solution through the plant’s root zone ensuring pH and EC levels are uniform throughout the entire system.
| Specifications | |||
|---|---|---|---|
| UC4XXL13 | UC6XXL13 | UC8XXL13 | |
| Number of Rows | 2 | 2 | 2 |
| Number of Sites | 4 | 6 | 8 |
Plant Spacing & Module Size | 40" Centers / 13 Gallon | 40" Centers / 13 Gallon | 40" Centers / 13 Gallon |
| System Dimensions | 4’6″ x 7’6.5″ / 1.37m x 2.30m | 4’6″ x 10’10.5″ / 1.37m x 3.31m | 4’6″ x 14’2.5″ / 1.37m x 4.33m |
Total System Volume (Reservoir) (gal/lt) | 58 / 220 | 80 / 303 | 105 / 398 |
| Power Usage | 91 Watts | 105 Watts | 155 Watts |
| Recommended Water Chiller (HP) | 1/4 HP | 1/4 HP | 1/4 - 1/2 HP |
