R-410A chlorine-free refrigerant Energy-efficient scroll compressor Low-pressure switch Liquid refrigerant return protection Factory-installed, bi-flow Liquid-line filter drier Service valves with sweat connections and easy-access gauge ports Copper tube/enhanced aluminum fin coil Reliable time-initiated, temperature-terminated defrost control Contactor with lug connection Ground lug connection Units meet the performance outlined in Table 6.8.1-2 of ASHRAE Standard 90.1-2013 AHRI Certified ETL Listed
| Specifications | |
|---|---|
| Cooling (BTU/h) | 56,500 |
| Heating Input | 59000 |
| EER | 12 |
| SEER | 14.00 |
| Rated Heating Conditions | Indoor (°F DB/WB): 80 / 67 Ambient (°F DB/WB): 95 / 75 |
| Holding Refrigerant Charge (lbs): | 205 |
| Refrigerant Type | R-410A |
| AC Volts/ Hz/ Phase | 208-230/ 60/ 3 |
| Min / Max Volts | 197/253 |
| Ship Weight (lbs) | 262 |
| Dimensions | 34-1/4 x 35-1/2 x 35-1/2 |
R-410A chlorine-free refrigerant Energy-efficient scroll compressor Low-pressure switch Liquid refrigerant return protection Factory-installed, bi-flow Liquid-line filter drier Service valves with sweat connections and easy-access gauge ports Copper tube/enhanced aluminum fin coil Reliable time-initiated, temperature-terminated defrost control Contactor with lug connection Ground lug connection Units meet the performance outlined in Table 6.8.1-2 of ASHRAE Standard 90.1-2013 AHRI Certified ETL Listed
| Specifications | |
|---|---|
| Cooling (BTU/h) | 56,500 |
| Heating Input | 59000 |
| EER | 12 |
| SEER | 14.00 |
| Rated Heating Conditions | Indoor (°F DB/WB): 80 / 67 Ambient (°F DB/WB): 95 / 75 |
| Holding Refrigerant Charge (lbs): | 205 |
| Refrigerant Type | R-410A |
| AC Volts/ Hz/ Phase | 208-230/ 60/ 3 |
| Min / Max Volts | 197/253 |
| Ship Weight (lbs) | 262 |
| Dimensions | 34-1/4 x 35-1/2 x 35-1/2 |
